(Cable should NOT be connected to your laptop yet. Only connect it when instructions say so.)
Windows XP, Vista, 7:
Bought ELM from Total Car Diagnostics?
Didn't buy ELM from Total Car Diagnostics?
Install all 4 driver packs below. Reason why so many to install is various ELM's use different hardware chips. So one pack below should work.
—
If you bought ELM cable from elsewhere (clones, eBay, other manufacturers) then install all Driver Packs below, because they cover widest range of chip makers
That's it!
Go to Step 2 below to test if everything is working ok
Windows 8,
Important: Any ZIP file below must be extracted specifically to Desktop. Then run the .exe file as Administrator. (Right-click > Run as Administrator)
Bought ELM from Total Car Diagnostics?
Didn't buy ELM from Total Car Diagnostics?
Install all 5 driver packs below. Reason why so many to install is various ELM's use different hardware chips. So one pack below should work.
That's it!
Go to Step 2 below to test if everything is working ok
(You can now CONNECT your ELM USB cable to any port on the laptop.)
Ok, we're almost ready to start scanning your vehicle.
First, let's ensure that everything is working fine!
Here's how
Step 1: Access Device ManagerWindows Vista/7/8/ Control Panel » System » Device Manager
Windows XP: Control Panel » System » "Hardware" tab » Device Manager
Step 2: Expand "Other Devices" and "Ports (COM & LPT)"Notice any device with any one of the following names:
- FTR USB UART
- Prolific USB-to-Serial
- USB Serial Port
- USBSerial
- Silicon Labs CPx USB to UART Bridge
NONE of above devices should have a yellow mark (
- Right-click on that device » Uninstall
- Unplug cable
- Restart PC
- Download and unextract DRIVER PACK 6
- Double-click on "InstallUSB" to install
- Connect cable to laptop. Yellow mark should now be gone. Success!
If yellow mark is STILL not gone after doing above, then do this:a) While cable is plugged in, right-click on device with the yellow mark.
b) Click on: Update Driver Software
c) Choose: Browser my computer for driver software
d) Browse to and select folder where you unextracted Driver Pack 6. Make sure "Include subfolders" is ticked ON.
e) Click on: Next
f) If you get RED warning, choose: Install this driver software anyway
g) After it installs successfully, another yellow mark may appear under "Other Device". Eg:
h) If g above is true, then do steps a-f for "Unknown Device". It may also show as "COMx".
Step 1: Install your OBD2 software (if you don't have it — checkout TOAD OBD software). Do NOT launch it yet.
Step 2: Connect ELM USB to your computer and car's OBD port (usually underneat dashboard/steering wheel).
Step 3: Place the key in the ignition and turn it forward to "ON" position. (Position where all dashboard lights are on. This is one position before engine starts.)
Step 4: Start your OBD diagnostic software. Click "Connect", and it should auto-connect to your vehicle. That's it!
TIP: If you want maximum data reported from the car — turn on the engine.
Yes, you can safely drive the vehicle while ELM is plugged in and application is monitoring car's data. Keep eyes on the road at all times.
| Troubleshooting: Solutions for ELM Connection Issues |
Common Solutions:
If you're unable to connect successfully to your car, then that's because of 2 reasons:
- Your vehicle is notOBD2 compatible.
- Random issues that can be fixed with below solutions
Here are solutions in recommended order:
- First check that ELM is physically working (not defunct). When you plug in the cable into a USB port, all the lights on ELM interface/device should flash. And then it'll return to 1 red light (power).
Condition of a defunct ELM interface: All lights will not initially flash, and only red light will be on. - Restart computer (while keeping cable connected to laptop). Try again.
- Plug USB into different physical port of your computer. Try again.
- If all above solutions fail, then we will help you (only if you are Total Car Diagnostics customer). Here's all you need to do
Connect ELM USB cable into laptop. (Don't need to plug the other end to car)
Step 1: Go to Control Panel.
Windows Vista/7/8/ Control Panel » System » Device Manager
Windows XP: Control Panel » System » "Hardware" tab » Device ManagerStep 2: Expand "Ports (COM & LPT)" and "Other Devices".
Step 3: Take picture of the screen (Press "Print Screen" key on the keyboard then paste into any graphics program. Or take shot with camera/phone.)
Step 4:Contact us and attach the picture.
Free Software To Test If ELM is Working with Windows and Vehicle
Step 1: Install EasyOBD. Do not launch it until Step 4 below.
Step 2: Connect ELM USB/Bluetooth to laptop and car.
Step 3: Turn on car ignition. (One step before engine turns on)
Step 4: Launch EasyOBD. It will automatically connect.
